CNC Machining Center (Model VCM-855)

    Buy cheap CNC Machining Center (Model VCM-855) from wholesalers

    Buy cheap CNC Machining Center (Model VCM-855) from wholesalers
    • Buy cheap CNC Machining Center (Model VCM-855) from wholesalers

    CNC Machining Center (Model VCM-855)

    Ask Lasest Price
    Brand Name : PERFECT
    Model Number : VCM-855
    Certification : ISO9001-2008
    Price : USD
    Supply Ability : 1000
    Delivery Time : 10
    Payment Terms : TT
    • Product Details
    • Company Profile

    CNC Machining Center (Model VCM-855)

    CNC Machining Center


    Model VCM-855



    Main Specification:

    SpecificationsunitVCM-855
    X/Y/Z axis
    X/Y/Z axis Strokemm800/550/550
    Distance from spindle center to column guidemm590
    Distance from spindle nose to table surfacemm120-670
    Worktable
    Worktable SzieMm1000x550
    Worktable Max.LoadKG500
    T-Slot
    Table T-solt(Number-width×pitch)mm5-18×90
    Spindle
    Spindle Taper7:24
    Spindle Rotation speedrpm8000
    Spindle Transmission TypeTiming belt
    Bearing Lubrication ModeOil-immersed Lubrication
    Spindle Motor PowerKW7.5
    Three AXES Motor PowerKW3.0
    Feeding
    X&Y Axis Fast Movementm/min.24
    Y Axis Fast Movementm/min.24
    Max. Cutting Feeding Speedm/min.10
    Auto Tool Changer System
    Tools Quantity (Standard)24
    Spindle TypeBT40
    Tools Clamping & LoosenPressure Increasing Cylinder
    Average Tool Change timeSecond3.5
    CNC System0i-MFJAPAN FANUC
    Accuracy
    Positioning Accuracymm±0.01
    Re- Positioning Accuracymm±0.01/300
    Machine WeightKG5000
    Air Pressure RequirementKg/cm²6
    Machine Overall DimensionMm3000x2300x2200
